Easy operation with easy-to-grip body and large buttons

The IC-M37 has a slim-designed body and big buttons, allowing for easy operation even while wearing gloves during fishing or sailing. This enables quick replies to calls. Additionally, the IC-M37 provides instant access to channel 16, as well as the Call channel.

Loud Audio Output

The IC-M37 provides a powerful 700 mW (typical) audio output. Received voice can be heard loud and clear. It helps you to hear calls even in noisy onboard environments.

12 Hours Long Time Operation

The BP-296 Li-ion battery pack, providing an operating time of approximately 12 hours for a full day of cruising or fishing experience. For added peace of mind during emergencies, the optional BP-297 battery case is also available.

*Approximate. Tx: Rx: Standby = 5 : 5 : 90.

IP57 Dust-tight and Waterproof Protection

The IC-M37 boasts exceptional IP57 waterproof protection, ensuring its safety even when submerged in water up to a depth of 1 meter for 30 minutes. Feel confident using it on deck or in dusty environments without any concerns.

Float'n Flash™ Function

If you accidentally drop the IC-M37 into the water, it will float, flash and sound an alarm. The buoyancy, the flashing light, and the sound reduce the risk of loss at sea even at night.

[youtube https://www.youtube.com/watch?v=Tt1RreNZlWs?version=3&rel=1&showsearch=0&showinfo=1&iv_load_policy=1&fs=1&hl=en-US&autohide=2&wmode=transparent&w=1300&h=732]

Float'n Flash Function Movie

AquaQuake™ Water Draining Function

The AquaQuake™ prevents audio degradation from a water-logged speaker. This function removes water from the speaker grill by vibrating the speaker cone. You can hear clear audio with this function.

6 W RF Output Power

The IC-M37's 6 Watts of transmit power provides extended communication range for the user.

Dualwatch and Tri-watch Functions

The Dualwatch and Tri-watch functions allow for periodic checking of Channel 16 while operating on another channel. This feature proves convenient when communicating with your friends' vessels or during sailing regattas, enabling you to make important announcements about the race.

Monitor Function

When receiving signal is weak and difficult to hear, you can use the Monitor function to open the squelch and help you hear the signal.

Additional features

Low Battery Alert function notifies you of low battery level

Voice Loud and Mute function enables to temporary maximize/mute the volume

Channel history function stores the last five channels used for easy recall

Various Scan functions (normal/priority)

Favorite Channel function

BP-296 user replaceable Li-ion battery pack supplied

Weather channels with Weather Alert function

Lock function

Power Save function

Backlight function for night time opeartion

LCD contrast selection

Supplied accessories

?   BP-296 battery pack

?   BC-235 desktop charger

?   BC-217SA/SE* AC adapter

?   FA-SC59V antenna

?   MB-133 belt clip

?   Hand strap

* May differ or not supplied, depending on the transceiver version.

General

Frequency range	TX	156.025–157.425 MHz
Frequency range	RX	156.050–163.275 MHz
Usable channel groups		INT, USA, CAN, WX channels
Type of emission		16K0G3E
Current drain (at 3.7 V DC)	TX (6.0 W/1.0 W output)	2.75 A/1.0 A
Current drain (at 3.7 V DC)	RX (Max. audio. Inter SP/Exter SP)	0.4 A/0.2 A
Operating temperature range		-20 °C to +60 °C, -4 °F to +140 °F
Antenna impedance		50 ?
Dimensions (W×H×D) (Projections not included)		59.7 × 140.5 × 38.7 mm, 2.4 × 5.5 × 1.5 in
Weight (approximate)		293 g, 10.3 oz (with BP-296, antenna and belt clip)

Transmitter

Output power (Hi/Low)	6 W/1 W
Max. frequency deviation	±5.0 kHz
Frequency stability	±10 ppm
Spurious emissions	–68 dBc typical

Receiver

Sensitivity (at 12 dB SINAD)		0.25 ?V typical
Squelch sensitivity (Threshold)		0.25 ?V typical
Adjacent channel selectivity		70 dB typical
Spurious response		70 dB typical
Intermodulation		70 dB typical
Hum and noise		40 dB
Audio output power (at 10% distortion)	Internal SP	0.7 W typical ( 8 ? load)
Audio output power (at 10% distortion)	External SP	0.3 W typical ( 4 ? load)
