Lowrance HDS PRO 9 Fishfinder/Chartplotter with C-MAP DISCOVER Onboard, No Transducer

🐟 HDS PRO 9 chartplotter/fishfinder display only, no transducer. The flagship 9-inch unit head only, for anglers replacing an HDS display or adding a second HDS PRO to an existing network.

About this product

Flagship HDS PRO tier, 9" SolarMAX HD touchscreen (1280x720, >1200 nits), premium processor, NMEA 2000, Wireless, Bluetooth, ActiveTarget 2 ready, Active Imaging HD ready (with compatible transducer), full network expansion.

Lowrance fishfinder line context: Eagle (entry tier) → Eagle Eye (premium Eagle) → Elite FS (mid-premium touchscreen with Active Imaging HD and network capability) → HDS PRO (flagship with premium processor, Active Imaging HD, and full network capability). Lowrance transducer naming: Bullet Skimmer (entry CHIRP) → Splitshot (CHIRP + Down Scan) → Tripleshot (CHIRP + Down Scan + Side Scan) → Active Imaging 3-in-1 (CHIRP + AI Down + AI Side) → Active Imaging HD (premium AI) → ActiveTarget 2 (live sonar, Lowrance equivalent to Garmin LiveScope and Humminbird MEGA Live 2).

Key Features

• ✅ HDS PRO 9 Fishfinder/Chartplotter with C-MAP DISCOVER Onboard, No Transducer. Flagship-tier or near-flagship Lowrance unit.
• ✅ SolarMAX HD Touchscreen. Viewable at extreme angles and through polarized lenses, ideal for direct sunlight conditions.
• ✅ Active Imaging HD Ready. High-definition up to 1.2MHz CHIRP/SideScan/DownScan Imaging (with compatible transducer).
• ✅ ActiveTarget 2 Live Sonar Ready. Plug-and-play support for ActiveTarget 2 Live Sonar (sold separately).
• ✅ FishReveal Sonar Views. SideScan and DownScan FishReveal helps identify fish vs structure.
• ✅ C-MAP DISCOVER Onboard pre-loaded. Pre-loaded mapping with 1-foot contours on 19,000+ US Lakes, 9,400+ Canadian Lakes.
• ✅ Real-Time Mapping. C-MAP Genesis Live creates custom contours as you fish.
• ✅ NMEA 2000, Wireless, Bluetooth Connectivity. Smartphone notifications and network expansion.
• ✅ Touchscreen Control of Add-Ons. Ghost Trolling Motor, Power-Pole Anchors, Autobathy, Lowrance Outboard Pilot, all controlled from the display.
• ✅ 3000 Waypoints, 100 Routes, 100 Trails. Tournament-grade waypoint capacity.
• ✅ 10 Hz GPS/GLONASS WAAS/EGNOS/MSAS. Fast, accurate position fix.

Who This Is For

This unit is best for tournament anglers replacing an HDS display, anglers networking dual-display HDS PRO rigs (bow + console), and anglers who already own a compatible Active Imaging HD transducer. Step up: see the next size HDS PRO. Step down: see Elite FS for the touchscreen mid-premium tier without HDS PRO processor.

Transducer Included

No transducer (display only, head unit only)

What's in the Box

• Lowrance HDS PRO 9 Fishfinder/Chartplotter with C-MAP DISCOVER Onboard, No Transducer display
• Documentation

FAQ

Q: HDS PRO vs Elite FS, what's the real difference?
HDS PRO has a more powerful processor (faster image refresh on Active Imaging HD), large programmable keys (10/12/16 inch models), full network expansion (radar, autopilot, multiple ActiveTarget displays), and is generally considered the tournament/professional tier. Elite FS is the mid-premium touchscreen tier with most of the same features at a lower price point but slower processing and reduced network expansion.

Q: Active Imaging HD vs Active Imaging 3-in-1 Gen 1?
Active Imaging HD operates at up to 1.2MHz (vs 800kHz on Gen 1) for higher-resolution SideScan and DownScan. Gen 1 is still excellent and was the industry standard for years. HD is worth the upgrade for shallow-water bass anglers who want maximum target separation in 0-30 ft water.

Q: Do I need a separate transducer?
If the title says "No Transducer", yes, you need to add a compatible transducer separately (Active Imaging HD 3-in-1 recommended). If the title includes "with Active Imaging HD" or "with Splitshot/Tripleshot", the transducer is included.

Q: Will this work with my Ghost trolling motor?
Yes. HDS PRO and Elite FS provide touchscreen control of Lowrance Ghost trolling motors, MotorGuide Xi5/Xi3 (with PinPoint Gateway), and other compatible motors. Ghost Trolling Motor 360 chart overlay is supported on HDS PRO.

Q: Can I add ActiveTarget 2?
Yes. All HDS PRO and Elite FS units are ActiveTarget 2 ready. Add the ActiveTarget 2 Sonar Module and Transducer (sold separately) for live forward-, down-, and scout-view sonar.

Q: NMEA 2000 networking?
Yes. NMEA 2000 backbone lets you connect multiple displays, radar, autopilot, engine data, AIS, and SiriusXM Weather/Audio. Network capability is one of the major reasons to choose HDS PRO over Elite FS.
