Description
TA62
Sensor
Resolution(pixel)
640×480
Pixel Size(µm)
12*12
NETD
?25mK(0.025°C)
Frame Rate(Hz)
50
Human Detection Distance(m)
1200/1500
Vehicle Detection Distance(m)
2500/2900
Optics
Objective Lens(mm)
25/35
Optical Magnification(x)
1.6/2.2
Digital Zoom(x)
2-8
PIP Zoom(x)
2
Continuous Digital Zoom
1.6-25.6/2.2-35.2
Field of View (Horizontal)
17.5°/12.5°
Field of View (Vertical)
13.1°/9.4°
Field of View (Diagonal)
21.7°/15.6°
Eye Relief(mm)
15
Diopter Adjustment(D)
±5
Display
Type
OLED
Resolution(pixel)
1024*768
Reticle Style
-
Reticle Color
-
Scene Mode
City/Rain/Forest
Image Mode
WT-HOT/BK-HOT/EDGE/RD-HOT/IN-HOT/SKY
Photo / Video
Photo Resolution(pixel)
-
Photo Format
.JPG
Video Resolution(pixel)
1024*768
Video Format
.mp4
Storage(GB)
SD card (Max. 128GB)
Image Engine
Pard IREA
Main Function
LRF Detection Range(m)
-
Ballastic Caculator
-
PIP
Yes
Gyroscope
-
Self-motivated Recording
-
Loop Recording
Yes
Red Dot
Yes
E-compass
Yes
Shutter
Mechanical shutter
Microphone
Yes
Illuminator
-
Firmware Upgrade
Yes
Connections
WiFi
Yes
Supported Apps
PardVision
Power Supply
Battery Type
Lithium lon 18650*1
Output Voltage(V)
3.7
Operating Time(h,max)
?5
External Power Supply(V)
Type-C
Environmental Characteristic
Integration of Protection
IP67
Operating Temp(°C/°F)
-20 ~ +50
Recoil Resistance(J)
-
Material
Housing
Aluminum Alloy + Composite
Objective Lens
All-glass multi-coated lens
Measurement
Product Dimension(L x W x H, mm)
165*68*44
