CORE CHARACTERISTICS:
Sensor Resolution:
640×512
Objective Lens:
60mm
Optical Zoom:
3
Display Resolution:
2560 x 2560
Operating Time:
8h
Sensor Specifications
Type
VOx Uncooled
Resolution, pixels
640×512
Pixel Pitch, µm
12
NETD, mK
?20
Frame Rate, Hz
60
Optical Specifications
Objective Lens?mm
60 F1.0
Optical Zoom, x
3
Field of View, degrees / yd @ 100 yd
7.3°×5.8°
Digital Zoom, x
1 to 6, stepped
Eye Relief, mm
60
Diopter Adjustment, D
-5 to +2
Detection Range, m/yd
3280
Display Specifications
Type
OLED
Resolution, pixels
2560 x 2560
LRF Specification
Type, nm
905
Max Range, yd
1200
Wi-Fi
Wireless Protocol
Wi-Fi
Frequency, GHz
2.4GHz
BT
Frequency, MHz
2402~2480
Video Recorder
Video / Photo Resolution, pixels
1280×1280
Video / Photo Format
.mp4 / .jpg
Built-in Memory, GB
64
Physical Specifications
Degree of Protection, IP code
IP67
Operating Temperature Range, °F
-4 to +122
Weight, lb
2.9
Dimensions, inch
10.3×3.3×3.8
Connections and Compatibilities
Battery Type
18650×2
Capacity, mAh
3800
Operating Time on Battery Pack (at t=72°F), h
8
External Power Supply, V
5V (Type C USB)
Max Recoil Power on Rifled Weapon (Eo), g/Joules
1000g/6000Joules
Compatible Mounts
-
