Description
Sensor Specifications
Type: VOx Uncooled
Resolution, pixels: 640×512
Pixel Pitch, µm: 12
NETD, mK: <25
Frame Rate, Hz: 50
Optical Specifications
Objective Lens mm: 35
Optic Zoom, x: 2
Field of View, degrees / yd @ 100 yd: 12.5°/21.9yd
Digital Zoom, x: 1 to 4
Eye Relief, mm: 48
Diopter Adjustment, D: -5 to +5
Detection Range, m/yd: 1800/1969
Display Specifications
Type: OLED
Resolution, pixels: 1024×768
Wi-Fi
Wireless Protocol: Wi-Fi
Frequency, GHz: 2.4GHz
Video Recorder
Video / Photo Resolution, pixels: 1024×768
Video / Photo Format: .mp4 / .jpg
Built-in Memory, GB: 32
Physical Specifications
Degree of Protection, IP code: IP67
Operating Temperature Range, °F: -4 to +122
Weight, lb: 0.97
Dimensions, inch: 5.3×2.5×2.2
Connections and Compatibilities
Battery Type: 18650
Capacity, mAh: 3200
Operating Time on Battery Pack (at t=72°F), h: 5
External Power Supply, V: 5V (Type C USB)
Max Recoil Power on Rifled Weapon (Eo), g/Joules: 1000g/6000Joules
Compatible Mounts: Picatinny mount
