AA battery life |
1 full season |
Number of pins |
12-pin (orange connector) |
Max thrust |
100 lbs per ISO 13342 using high efficiency propeller at 36 V
80 lbs per ISO 13342 using high efficiency propeller at 24 Vdc |
Foot pedal compatible |
Yes |
Voltage |
24 V or 36 V |
Dimensions |
12" L x 9" W x 4 1/2" H |
Gesture features |
yes (manual+, heading hold+, jog+) |
Wireless remote |
yes (included) |
Display resolution |
240 x 240 pixels |
Battery indicator |
Yes |
Wireless communication |
Yes |
Display type |
color, sunlight-visible, transflective memory-in-pixel (MIP) |
Cruise control |
Yes |
Lighted direction indicator |
Yes |
Color |
white |
Mounting location |
bow |
Battery life |
typical use with backlight at low, 43.2 weeks |
Deck stabilizer |
yes (90" only) |
Water rating |
IPX7 |
Depth/speed/temperature |
depth and temperature |
Electric steering |
Yes |
Display size |
1.2" (30.4 mm) diameter |
Water rating |
IPX7 |
quatix remote control supported |
Yes |
For use in |
freshwater, brackish water and saltwater |
Heading hold |
Yes |
Lift-assist |
No |
Foot pedal |
No |
Power installation |
12V wired or battery powered (2 AA) |
Water rating |
IPX7 |
Built-in GPS |
yes (dual frequency GPS) |
Warranty |
3-year, limited lifetime on shaft |
Built-in heading sensor |
Yes |
Autopilot feature control |
Yes |
Variable speed control |
yes (20 steps) |
Mount style |
pivot-style mount |
LiveScope cable integration |
yes (LiveScope transducer and Kraken Mounting Bracket purchases required) |
Adjustable pedal resistance |
Yes |
Route following |
Yes |
Anchor lock |
Yes |
Chartplotter user-programmable keys |
Yes |
