Description
- Force® Kraken Trolling Motor
- GT56UHD-TR transducer
- Remote
- High efficiency propeller
- Assembly and mounting hardware
- Documentation
Physical & Performance
| Floats | Yes |
Features
| AA battery life | 1 full season |
| Transmit power | Traditional: 350 W ClearVü/SideVü: 500 W |
| Number of pins | 12-pin (orange connector) |
| Max thrust | 100 lbs per ISO 13342 using high efficiency propeller at 36 V 80 lbs per ISO 13342 using high efficiency propeller at 24 Vdc |
| Foot pedal compatible | Yes |
| Voltage | 24 V or 36 V |
| Dimensions | 12" L x 9" W x 4 1/2" H |
| Gesture features | yes (manual+, heading hold+, jog+) |
| Wireless remote | yes (included) |
| Display resolution | 240 x 240 pixels |
| Battery indicator | Yes |
| Wireless communication | Yes |
| Display type | color, sunlight-visible, transflective memory-in-pixel (MIP) |
| Cruise control | Yes |
| Lighted direction indicator | Yes |
| Color | black |
| Mounting location | bow |
| Battery life | typical use with backlight at low, 43.2 weeks |
| Deck stabilizer | No |
| Water rating | IPX7 |
| Depth/speed/temperature | depth and temperature |
| Electric steering | Yes |
| Display size | 1.2" (30.4 mm) diameter |
| Water rating | IPX7 |
| quatix remote control supported | Yes |
| For use in | freshwater, brackish water and saltwater |
| Heading hold | Yes |
| Lift-assist | No |
| Frequencies supported |
CHIRP sonar: High-wide CHIRP (150-240 kHz) ClearVü: 455 kHz (425-485 kHz), 800 kHz (790-850 kHz), 1000 kHz (940-1100) SideVü:455 kHz (425-485 kHz), 800 kHz (790-850 kHz), 1000 kHz (940-1100) |
| Foot pedal | No |
| Power installation | 12V wired or battery powered (2 AA) |
| Water rating | IPX7 |
| Built-in GPS | yes (dual frequency GPS) |
| Warranty | 3-year, limited lifetime on shaft |
| Built-in heading sensor | Yes |
| Autopilot feature control | Yes |
| Maximum depth | CHIRP sonar: 800 ft freshwater ClearVü: 400 ft; SideVü: 500 ft |
| Variable speed control | yes (20 steps) |
| Mount style | pivot-style mount |
| LiveScope cable integration | yes (LiveScope transducer and Kraken Mounting Bracket purchases required) |
| Adjustable pedal resistance | Yes |
| Route following | Yes |
| Anchor lock | Yes |
| Chartplotter user-programmable keys | Yes |
