Description
| Dimension | 8.6" x 5.6" x 3.2" (21.8 x 14.2 x 8.1 cm) |
|---|---|
| Touchscreen | X |
| Input | Touchscreen with Keyed Assist |
| Display Size | 6.1" x 3.4", 7.0" (15.5 x 8.7 cm, 17.8 cm) |
| Display resolution | 800 x 480 pixels |
| Display Type | WVGA, TN |
| Weight |
2.2 lbs (1.0 kg) |
| Waterproof |
IPX7 |
| Mounting Options | Bail or flush |
Maps & Memory |
|
| Accepts Data Cards |
1 microSD™ card; 32 GB maximum size |
|---|---|
| Waypoints |
5,000 |
| Track points | 50,000 |
| Tracks | 50 saved tracks |
| Navigation Routes | 100 |
Sensors |
|
| Has built-in receiver | X |
|---|---|
| Receiver |
10 Hz |
| NMEA 2000 Compatible | X |
| GPS | X |
| GLONASS | X |
| Galileo | X |
| BeiDou | X |
| Supports WAAS | X |
| Supports multi-band, multi-constellation GPS | X |
Built-in Maps |
|
| Built-in Auto Guidance+ | yes (downloadable via ActiveCaptain app) |
|---|---|
| Garmin Navionics+ Inland & Coastal | yes (see Additional) |
| Garmin Navionics+ (Coastal) | yes (see Additional) |
| Garmin Navionics+ (Inland) | yes (see Additional) |
| Tide tables | yes (see Additional) |
Optional Map Support |
|
| Garmin Navionics+™ | |
|---|---|
| Garmin Navionics Vision+™ | |
| TOPO | |
| Standard Mapping | |
| Garmin Quickdraw Contours | |
Chartplotter Features |
|
| AIS | |
|---|---|
| DSC | |
| Supports Fusion-Link™ compatible radios | |
| ActiveCaptain® compatible | |
| Sailing Features | |
Electrical Features |
|
| Power Input | 9 to 18 Vdc |
|---|---|
| Typical current draw at 12 Vdc | 1.52 A |
| Maximum current draw at 12 Vdc | 3.2 A |
| Maximum power usage at 10 Vdc | 18.3W |
Sonar Features & Specifications |
|
| Displays sonar | |
|---|---|
| Power output | 500 W |
| Traditional sonar (dual frequency/beam) | built-in (single channel CHIRP, 50/77/83/200 kHz, L, M, H CHIRP) |
| ClearVü | built-in 260/455/800/1000/1200 kHz |
| SideVü | built-in 260/455/800/1000/1200 kHz |
| Panoptix™ sonar | |
| LiveScope | |
Connections |
|
| NMEA 2000® ports | |
|---|---|
| Garmin Marine Network Ports |
1 |
| 12-pin transducer ports | 1 |
| BLUETOOTH® pairing | X |
| ANT+ (Connectivity) | X |
| Garmin Wi-Fi network (local connection) | X |
Additional |
|
