Garmin GT360UHD 360 Degree Scanning Sonar Transducer for Spy Pole Mount
SKU:
Description
The Garmin GT360UHD (part 010-03012-10) is a 360 degree scanning sonar transducer that mounts on Garmin's Spy Pole motorized pole mount. It spins to show OneVu 360 degree imaging all the way around the boat, so you can see brush piles, docks, bait and fish on every side without moving the boat, then cast right to them.
What It Shows You
- OneVu 360 degree imaging around the boat at 455, 800 or 1,070 kHz.
- SideVu style scanning out to 500 feet of range.
- Water temperature and depth from the built-in sensors.
Will It Fit My Garmin?
Garmin lists the GT360UHD for ECHOMAP UHD2 sv and ECHOMAP Ultra 2 chartplotters, GPSMAP 723, 743, 923, 943, 1223, 1243, 1523, 1543, 1623 and 1643 xsv units, GPSMAP 8400 and 8600 xsv and GPSMAP 9000 and 9200 xsv units, plus the Spy Pole mount. It uses a 12-pin plug. The Spy Pole motorized pole mount is sold separately; Garmin includes the transducer mount for Spy Pole, a LiveScope adjustable perspective shaft mount and a dogbone stabilizer. Call us with your exact model and we will confirm it before you buy.
Which One Do I Need?
Pick the GT360UHD when you already run, or plan to add, a Garmin Spy Pole and want to see all the way around the boat. It is not a replacement for the transducer in a Force nose cone. Many anglers run it beside LiveScope on the Spy Pole to find cover in 360 and then watch fish live.
Specs
- Sonar: OneVu and SideVu at 455, 800 and 1,070 kHz, 500 W
- Beams: 1.1 by 52 degrees at 455 kHz, 0.64 by 35 degrees at 800 kHz, 0.52 by 52 degrees at 1,000 kHz
- Range (Garmin rating): 500 ft
- Sensors: depth and water temperature
- Cable: 20.3 ft (6.2 m)
- Connector: 12-pin
- Size with mount: 8.5 by 2.3 by 3.8 inches
In the Box
- GT360UHD 12-pin transducer
- GT360UHD transducer mount for Spy Pole
- LiveScope adjustable perspective shaft mount
- Dogbone stabilizer
- Mounting hardware
- Documentation
Pros and Cons
- Pro: Full 360 degree view around the boat
- Pro: Spy Pole mount, perspective shaft mount and stabilizer included
- Pro: Pairs with LiveScope on the Spy Pole
- Con: Spy Pole motorized mount sold separately
- Con: Needs a compatible UHD sv or xsv unit
Frequently Asked Questions
Do I need a Spy Pole?
Yes. Garmin built the GT360UHD for the Spy Pole motorized pole mount, which is sold separately.
GT360UHD vs MEGA 360?
Both give 360 degree imaging. The GT360UHD is Garmin's version for Garmin units and the Spy Pole; MEGA 360 is Humminbird's for Humminbird units.
Does it work on an ECHOMAP UHD2 cv?
No. Garmin lists sv and xsv units only.
