| Type |
VOx Uncooled |
| Resolution, pixels |
384×288 |
| Pixel pitch, μm |
12 |
| NETD, mK |
<25 |
| Frame Rate, Hz |
50 |
|
| Optical Specifications |
Objective Lens，mm |
35 |
| Optic Zoom, x |
3.5 |
| Field of View, degrees / yd @ 100 yd |
7.5°/13.2yd |
| Digital Zoom, x |
1 to 4 |
| Eye Relief, mm |
48 |
| Diopter Adjustment, D |
-5 to +5 |
| Detection Range, m/yd |
1800/1968 |
|
| Display Specifications |
Type |
OLED |
| Resolution, pixels |
1024×768 |
|
| Wi-Fi |
Wireless Protocol |
Wi-Fi |
| Frequency, GHz |
2.4GHz |
|
| Video Recorder |
Video / Photo Resolution, pixel |
1024×768 |
| Video / Photo Format |
.mp4 / .jpg |
| Built-in Memory, GB |
32 |
|
| Physical Specifications |
Degree of Protection, IP code |
IP67 |
| Operating Temperature Range, °F |
-4 to+122 |
| Weight, lb |
0.97 |
| Dimensions, inch |
5.3×2.5×2.2 |
|
| Connections and Compatibilities |
Battery Type |
18650 |
| Operating Time on Battery Pack (at t=72°F), h |
4.5 |
| External Power Supply, V |
5V (Type C USB) |
| Max Recoil Power on Rifled Weapon (Eo), g/Joules |
1000g/6000Joules |
| Compatible Mounts |
Picatinny mount |
